1: | Insertion Loss at 23℃: 13,5 dB | 2: | Channel Uniformity: 1,4 dB |
---|---|---|---|
3: | PDL: 0,3 dB | 4: | Operating wavelength: 1260~1650 |
5: | Return Loss: 55 dB | 6: | Directivity : 55 dB |
7: | Operating Temperature: -40~85 | 8: | Storage Temperature: -40~85 |
9: | Fiber Type : G.657.A1/G657.A2/G.652.D | 10: | Basic Type PLC Splitter: 4×4×50 mm |
11: | 900um Fan-out Type PLC Splitter: 4×4×50 mm | 12: | 900um SFF Type PLC Splitter: 4×12×60(60) mm |
13: | Module Type PLC Splitter: 18×80×120 mm |
